PP String Wound Filter Cartridge

PP String Wound Filter Cartridge

PP sediment string wound filter cartridge is using 100% food grade Polypropylene(PP) as material,and it does not contain any adhesives.By special production technology to control the diameter of PP filter,the micro rate of filter cartridge is controlled.Each micron rate has its string pattern to ensure the filtration effect.

PP String Wound Filter Cartridge Application:

Pre-filtration or RO system, solvent, chemical industry, oil industry, drinking water treatment, electronic and power industries, oli industry, plating, food and beverage, wine, ect.

Filter Cartridge

PP String Wound Filter Cartridge Main Features

High filtration precision, and small pressure difference.

Small resistance and large flow.

Excellent adsorptive capacity and long service life.

The filter aperture is small inside and big outside, with good deep filtration effect.

Non-toxic and tasteless, no secondary pollution

PP String Wound Filter Cartridge SPEC. Table

Material

Polypropylene, absorbent cotton, glass fibre

Support Layer

PP/Stainless steel

Filtration pore size

1um, 3um,5um,10um,20um,30um,50um,80um,100um

Outer diametr

58mm--65mm

Inner diameter

28mm or 30mm

Length

5'',10'',20'',30'',40''

Max Postitive Pressure

Not higher than 0.4 MPa

Max Back Pressure

Not higher than 0.2MPa

Recommended Clean/change pressure differential

0.2MPa

Max operating temperature

PP with PP core:60oC
PP with SS core: 100oC
Absorbent cotton with SS core:120oC
Glass fibre with SS core: 180~300oC
