Home > Filtration Products > Bag filter vessel

Stainless steel bag filter vessel

About bag filtration, inside the bag filtration system, the filter bag is supported by an inside metal basket. The incoming fluid flow out after filtered by the bag, and the impurities are intercepted in the filter bag. You can continue to use the filtration system after changing the filter bag.
When looking for a cost-effective single bag filter vessel that is both durable and reliable, look to the bag filter vessels.

If the order quantity can be more than 5 units, we will quote the lowest price for you ! Contact with us now.


SIDE IN BAG FILTER HOUSING PICTURE


Bag filter vessel specification

Housing Materials 304 stainless steel
316 stainless steel
Carbon steel

Gasket Materials NBR
EPDM
Viton
Viton & Teflon encapsulated

Number of Bags 1

Filter Bag Size 1,2,3,4

Maximum Operating Pressure 1.0Mpa (10bar)

Design Temperature Range Carbon Steel: 20 to 500°F (-6 to 250°C)
Stainless Steel: -20 to 250°F (-28 to 121°C)

Connections
Flange or NPT

Surface Finish Carbon Steel: Paint spraying
Stainless Steel: Light sand blast


Bag filter vessel application

---Paints, Coating, Inks, Dispersions
---Water and Water Treatment
---Solvents
---Lubricants, Metalworking Fluids
---Parts Cleaning Solutions
---Pulp and Paper
---Pharmaceutical
---Food Processing
---Chemical Processing
---Edible Oils
---Potable Water, Beer, Wine
---Automotive

stainless steel bag filter housing

Bag filter vessel model table

Model Max Flow(m3/h) Max pressure Pipe Size Material
S403-304-G25 5 10bar 1" 304/316
S404-304-G25 10 10bar 1" 304/316
S401-304-G50 20 10bar 2" 304/316
S402-304-G50 40 10bar 2" 304/316/CS
Please send us the bag filter vessel specification detail by email for quote, thanks.
